FSTH-FG300D
This directional signal suppression technology projects high-intensity interference waves to establish a cylindrical defense perimeter, disrupting critical UAV operator communications and satellite positioning data. Through targeted electromagnetic intervention, it creates an electronic barrier that severs drone control links and navigation capabilities. Based on target UAV configurations, the system enforces flight termination protocols including forced return-to-origin, emergency grounding, or stabilized aerial suspension. Equipped with a 360° motorized gimbal, the device ensures omnidirectional protection for diverse security applications across military, judicial, aviation, diplomatic, energy, and critical infrastructure sectors, as well as large-scale public events like athletic competitions, concerts, and expositions.
Core Capabilities
Adaptive Termination Protocols: Disrupts navigation systems, control channels, and visual data streams of commercial/professional UAVs with selectable neutralization modes (grounding/return command)
Extended Engagement Capacity: High-efficiency directional array antennas enable long-distance signal interception (>3km operational radius)
Multi-Spectral Jamming: Modular interference emission across 10+ frequency bands with simultaneous/selective activation
Operational Feedback System: Per-band LED status indicators for real-time performance monitoring
Smart Operation Features: Remote management compatibility with automated power regulation to minimize electromagnetic pollution
Technical Specifications
Frequency Coverage:
400/800/900MHz, 1.2/1.4/1.5GHz, 2.4GHz, 5.1/5.4/5.8GHz
Neutralization Modes: Signal disengagement & forced landing protocols
Effective Radius: >3km (environmental/UAV model dependent)
Control Interfaces: RJ45 Ethernet & RS485 serial communication
Power Draw: ≤900W peak consumption
Positioning Systems: Dual-mode GPS/BeiDou compatibility
Environmental Resilience:
Operational Range: -40°C to +60°C
Humidity Tolerance: 10%-95% non-condensing
Physical Profile:
Dimensions: 489×461×291mm
Weight: ≤30kg
Protection Class: IP65 weatherproof rating
Continuous Operating Time: Supports outdoor 7x24-hour use
