FSTH-210R
This advanced counter-UAV solution utilizes omnidirectional antennas to transmit high-intensity jamming signals, creating an electronic perimeter barrier that disrupts target drones' operations. By blocking command links and satellite navigation signals, it effectively severs communication between UAVs and their operators while neutralizing positioning capabilities. The system initiates protocol-driven responses based on drone configurations, compelling targets to execute return-to-home procedures, emergency landings, or stationary hovering.
Deployment Scenarios
Widely deployed across diverse security sectors including:
Military installations and border protection
Judicial complexes and diplomatic compounds
Critical infrastructure (airports, power plants, petrochemical facilities)
Commercial applications extend to major public events such as:
Athletic competitions and stadium events
Live concerts and exhibition venues
Core Technical Advantages
360° full-coverage defense against simultaneous drone threats
Multi-spectrum jamming capability covering 400MHz-5.9GHz frequencies
Ruggedized design for harsh environments (IP65-rated waterproof/dustproof)
Performance Specifications
| Covered Frequency Bands | 400MHz, 800MHz, 900MHz, 1.2GHz, 1.4GHz, 2.4GHz, 5.1-5.9GHz |
| Effective Range | ≥2 kilometers |
| Operational Tolerance | -40°C to +60°C |
| Environmental Resistance | ≤95% humidity |
| Control Interface | Ethernet (RJ45) |
| Power Requirements | ≤600W consumption |
| Physical Dimensions | 489×461×233mm (L×W×H) |
| System Weight | ≤30kg |
| Protection Rating | IP65 certified |
